Catalog
Unit of Measure
Current Rating |
N/A 20 A |
Underwriters Laboratories (UL) Voltage Rating |
N/A 300 V |
Underwriters Laboratories (UL) Current Rating |
N/A Not listed |
Canadian Standards Association (CSA) Current Rating |
N/A Not listed |
Brands |
N/A Elec-Tron |
Number of Tabs |
N/A 4 x 2 Poles |
Number of Poles |
N/A 2 |
Canadian Standards Association (CSA) File |
N/A 1724185 |
Underwriters Laboratories (UL) File |
N/A E61937 |
Underwriters Laboratories (UL-94) Flammability |
N/A V1 |
Underwriters Laboratories (UL) Temperature Rating |
N/A 150 ºC |
Underwriters Laboratories (UL) Wire Size for Torque |
N/A 6-14 AWG Copper Only |
Canadian Standards Association (CSA) Voltage Rating |
N/A 300 V |
Accessories |
N/A INS-EB can be added to increase voltage from 300V to 600V |
