Catalog
Unit of Measure
Current Rating |
N/A 75 A |
Underwriters Laboratories (UL) Voltage Rating |
N/A 600 V |
Underwriters Laboratories (UL) Current Rating |
N/A 75 A |
Canadian Standards Association (CSA) Current Rating |
N/A 70 A |
Brands |
N/A Elec-Tron |
Number of Tabs |
N/A Connectors Only |
Number of Poles |
N/A 1 |
Canadian Standards Association (CSA) File |
N/A 2606851 |
Underwriters Laboratories (UL) File |
N/A E61937 |
Underwriters Laboratories (UL-94) Flammability |
N/A V1 |
Underwriters Laboratories (UL) Temperature Rating |
N/A 150 ºC |
Canadian Standards Association (CSA) Voltage Rating |
N/A 600 V |
Underwriters Laboratories (UL) Copper Wire Range |
N/A 2-14 AWG |
Underwriters Laboratories (UL) Aluminum Wire Range |
N/A 2-10 AWG |
Underwriters Laboratories (UL) Tightening Torque |
N/A 35-45 in·lb |
Canadian Standards Association (CSA) Wire Range (Copper or Aluminum) |
N/A 4-14 AWG |
Canadian Standards Association (CSA) Tightening Torque |
N/A 35-45 in·lb |
