Catalog
Unit of Measure
Current Rating |
N/A 20 A |
Underwriters Laboratories (UL) Voltage Rating |
N/A 300 V |
Underwriters Laboratories (UL) Current Rating |
N/A Not listed |
Canadian Standards Association (CSA) Current Rating |
N/A Not listed |
Brands |
N/A Elec-Tron |
Number of Tabs |
N/A 2 x 2 Poles |
Number of Poles |
N/A 2 |
Canadian Standards Association (CSA) File |
N/A 1742185 |
Underwriters Laboratories (UL) File |
N/A E61937 |
Underwriters Laboratories (UL) Temperature Rating |
N/A 150 ºC |
Underwriters Laboratories (UL) Voltage Rating For Commercial Appliances |
N/A 250 V |
Underwriters Laboratories (UL) Tightening Torque for 25 Ampere (A) Current Rating and 10-14 American Wire Gauge (AWG) Copper Only Wire Range |
N/A 16 in·lb |
Underwriters Laboratories (UL) Tightening Torque for 50 Ampere (A) Current Rating and 4-6 American Wire Gauge (AWG) Copper or Aluminum Wire Range |
N/A 35 in·lb |
Underwriters Laboratories (UL) Tightening Torque for 50 Ampere (A) Current Rating and 8 American Wire Gauge (AWG) Copper or Aluminum Wire Range |
N/A 25 in·lb |
Underwriters Laboratories (UL) Tightening Torque for 50 Ampere (A) Current Rating and 10-14 American Wire Gauge (AWG) Copper or Aluminum Wire Range |
N/A 20 in·lb |
Canadian Standards Association (CSA) Wire Range for 15 Ampere (A) Current Rating |
N/A 14 AWG |
Canadian Standards Association (CSA) Wire Range for 25 Ampere (A) Current Rating |
N/A 10-12 AWG |
