Catalog
Unit of Measure
Current Rating |
N/A 120 A |
Underwriters Laboratories (UL) Voltage Rating |
N/A 300 V |
Underwriters Laboratories (UL) Current Rating |
N/A 120 A |
Canadian Standards Association (CSA) Current Rating |
N/A 120 A |
Brands |
N/A Elec-Tron |
Number of Tabs |
N/A 6 x 3 Poles |
Number of Poles |
N/A 3 |
Canadian Standards Association (CSA) File |
N/A 1742185 70063225 |
Underwriters Laboratories (UL) File |
N/A E61937 |
Underwriters Laboratories (UL-94) Flammability |
N/A V1 |
Underwriters Laboratories (UL) Temperature Rating |
N/A 150 ºC |
Underwriters Laboratories (UL) Wire Size for Torque |
N/A 1/0-14 AWG Copper or Aluminum |
Canadian Standards Association (CSA) Voltage Rating |
N/A 300 V |
Canadian Standards Association (CSA) Wire Range |
N/A 1/0-14 AWG Copper Only |
Wire Size for Torque |
N/A 1/0-3 AWG Wire Size for 50 in·lb Torque 10-14 AWG Wire Size for 35 in·lb Torque 4-6 AWG Wire Size for 45 in·lb Torque 8 AWG Wire Size for 40 in·lb Torque |
Accessories |
N/A INS-ERB or INS-ERB2 can be added to increase voltage from 300V to 600V |
